America's Leader in 4-Sided Galvanized Steel Strip
Engineered for precision. Trusted for strength. Delivered with consistency.
Arrowstrip manufactures 4-sided hot dip galvanized steel strip in oscillated coil form — produced to exacting tolerances, coated for complete corrosion protection, and built for the most demanding industrial applications.
Built on Precision.
Backed by Integrity.
Arrowstrip was founded with one goal in mind: to deliver premium galvanized steel strip that meets the strictest industry standards. As a trusted manufacturer of 4-sided galvanized steel, we’ve earned a reputation for our consistency, craftsmanship, and customer-first approach.
We proudly operate in the heart of America’s manufacturing belt, offering personalized service and timely delivery to customers in the U.S. and around the world. Our team is driven by experience, and every product we ship reflects our unwavering commitment to quality.
Our Promise
Our name is on every coil.
- ConsistencyTight, repeatable tolerances on every run, every order.
- CraftsmanshipProprietary oscillating machinery and laser-controlled slitting.
- Customer-FirstPersonalized service, rapid fulfillment, and custom packaging.
4-Sided Hot Dip Galvanized Steel Strip Built for Performance
We manufacture a full line of 4-sided galvanized steel strip in oscillated coil form. Designed for demanding applications, our strip is produced to exacting tolerances and coated to withstand harsh environments — ideal for structural, industrial, and specialty applications.
- Smooth, uniform galvanized coating on all four surfaces
- Oscillated coil & ribbon-wound formats
- Custom packaging and private labeling available
Available Sizes & Specifications
Oscillating Line
| Specification | U.S. | Metric |
|---|---|---|
| Thickness Range | .010″ to .050″ | .25 to 1.78 mm |
| Width Range | .187″ to 1.25″ | 4.75 to 31.75 mm |
| Coil Face | 2.5″ to 12″ | 63.5 to 304.80 mm |
| Maximum O.D. | 36″ | 914.4 mm |
| Coil I.D. | 14″ or 16″ | 355.6 to 406.4 mm |
| Coil Weight | 400 to 2000 lbs | 181 to 909 kg |
Ribbon Wound
| Specification | U.S. | Metric |
|---|---|---|
| Thickness Range | .010″ to .050″ | .25 to 1.78 mm |
| Width Range | .750″ to 3″ | 19.05 to 76.20 mm |
| Maximum O.D. | 40″ | 1016 mm |
| Coil I.D. | 2″ or 16″ | 355.6 to 406.4 mm |
| Coil Weight | Varies with width | Varies with width |
Your Standards Are Our Baseline
Quality control is built into every stage of production. We use a multi-point inspection process, precision measurement tools, and trained personnel to ensure each coil meets your exact specifications — with batch-level documentation and full traceability.
Tolerance Tracking
Dimensional tolerances measured and recorded at every checkpoint.
Zinc Coating Verification
Coating weight and uniformity verified on all four surfaces.
Surface Assessment
Visual and instrumented surface quality inspection on every coil.
Batch Reports
Full batch-level documentation available upon request.
We don’t believe in cutting corners. Our name is on every coil — and we take that seriously.
Equipment.
Experience. Execution.
Our facility is equipped with advanced shaping, drawing, and galvanizing lines capable of meeting a wide range of specifications — from high-volume standard orders to low-volume specialty runs.
Master Coil Slitting — 48″
| Minimum Thickness | .010″ |
| Maximum Thickness | .050″ |
| Incoming Max. Coil O.D. | 58″ |
| Incoming Coil I.D. | 15″, 20″, or 24″ |
| I.D. Coming Off The Line | 16″ or 24″ |
| Maximum Coil Width | 48″ |
| Minimum Coil Width | 12″ |
| Maximum Coil Weight | 25,000 lbs. |
What We Offer
- 1
In-Line Galvanizing
Uniform 4-sided coating applied after slitting for complete protection.
- 2
Oscillated Coil Winding
Efficient packaging for streamlined shipping and end-use feeding.
- 3
Tight-Tolerance Drawing
Consistent dimensions across every coil and every order.
- 4
Rapid Order Fulfillment
Flexibility to deliver standard high-volume and specialty low-volume runs.
- 5
Custom Labeling & Branding
Private labeling and custom packaging to your requirements.
Arrowstrip continues to invest in our people and technology to ensure our partners receive industry-best product every time.
Shipping to 16+ Countries Worldwide
From our facility in the heart of America’s manufacturing belt, Arrowstrip delivers 4-sided galvanized steel strip to customers across North America and around the world. Accommodations are made for customers requiring international shipping — including export packaging, private labeling, and documentation to meet the requirements of each destination.
Recognized for international export performance, our coils reach partners on multiple continents while holding the same precision tolerances and four-sided protection every order depends on.
Ready to Spec Your Next Order?
Custom sizes, rapid delivery, and four-sided protection you can count on.
Let’s Talk Specifications
Contact us with any questions you may have concerning specifications, custom sizing, or international shipping.
Arrowstrip, Inc.
100 South First Street
Martins Ferry, OH 43935
Established 1961
Martins Ferry, Ohio — Serving North America & beyond
